Parker SSD 890CS 162A Common DC Bus Supply for 890 Series

Parker SSD 890 Series Common DC Bus Supply unit for use with 890 series Inverters.

** Limited Availability - 890 Product becoming Obsolete Q3 2025**

Size D: 160mm Wide x 260mm Deep x 433mm High. IP20.

Input Rating is 162A Continuous
Output Rating is 200A DC Continuous
Output Power Rating:-
at 380V/415V input - 90kW (120HP)
at 208V/230V input - 45kW (60HP)
at 460V input - 100kW (135HP)
at 500V input - 110kW (147HP)

Includes a brake switch for use with an external resistor  - See the Resistor options linked below or use the 'Which Resistor' button on this page.
Maximum brake switch rating is 100A continuous.
Minimum brake resistance:-
at 380V/415V input is 7.3 Ohms
at 208V/230V input is 4.0 Ohms
at 460V input is 8.1 Ohms
at 500V input is 5.5 Ohms
(or use nominal supply Voltage x 1.76/100A)

Manufacturer is Parker SSD Drives.
Full Part number is 890CS-533162D0-B00-U. Legacy part number is 890CS/5/0162D/B/00/N/EN/00/00.
Model number 890CS-5-0162D

Download the Parker 890 Common DC Bus Quick Start Manual from the links below:-
