Delta 1.27Nm 3000RPM x 220V AC Servo Motor ECMA-C20642RS

ECMA-C20604RS

Order Code: 39612
Photo of Delta 1.27Nm 3000RPM x 220V AC Servo Motor ECMA-C20642RS
Obsolete Product
This item is now obsolete. Alternatives may be available - see linked products below.

Brand: Delta, Range: ECM-B3 Servo Motors

ECMA Low inertia 60mm AC Servo Motor with 17 bit incremental / single turn absolute encoder.

Rated Power Output: 400W (Derate 10% for Oil Seal).
Speed and Voltage: 3000RPM at 220V
Maximum Speed: 5000RPM at reduced torque (see torque curves in the data sheet linked below)
Rated Torque: 0.64Nm (Derate 10% for Oil Seal).
Peak Torque: 2.24Nm (Derate 10% for Oil Seal).
Rated Current: 2.6A
Peak Current: 7.8A
Compatible with ASD-A2-0421x servo drive, see the products linked below.

Size 06: 60mm Square x 130mm Long body including the resolver and excluding the register and shaft.
Mounting: Flange mount on 5.5mm dia holes at 70mm pcd with 50mm dia register.
Shaft:  14mm dia x 27mm long with oil seal, 11mm x 20 key.
Encoder: 17 bit incremental with resolver as single turn absolute encoder.
Connector:  Standard
IP Rating: IP67
Inertia:  0.277kgcm²
Weight: 1.8kg

Part Number: ECMA-C20604RS
